wiped thin film evaporator

A wiped thin film evaporator represents a sophisticated piece of industrial equipment designed for continuous, efficient processing of heat-sensitive materials. This advanced system operates by creating an extremely thin film of product on a heated cylindrical surface, which is continuously wiped by rotating blades. The process ensures rapid heat transfer and short residence time, making it ideal for processing temperature-sensitive materials. The equipment's design incorporates a vertical, cylindrical heating jacket surrounding an internal rotor fitted with adjustable wiping blades. These blades maintain an optimal product film thickness while promoting turbulent flow and enhanced heat transfer. The system's sophisticated design allows for processing materials with high viscosities, managing crystallizing products, and handling fouling substances effectively. In industrial applications, wiped thin film evaporators excel in various processes including concentration, purification, degassing, and drying of complex materials. The technology finds extensive use in pharmaceutical, chemical, food, and petrochemical industries, where precise temperature control and minimal product degradation are crucial. The equipment's ability to operate under vacuum conditions further expands its capabilities, enabling the processing of heat-sensitive materials at lower temperatures while maintaining product integrity.

Popular Products

Wiped thin film evaporators offer numerous compelling advantages that make them indispensable in modern processing operations. The primary benefit lies in their ability to handle heat-sensitive materials with exceptional care, preventing thermal degradation through precise temperature control and minimal residence time. This technology excels in processing high-viscosity materials that would be challenging or impossible to handle in conventional evaporators. The continuous wiping action ensures uniform heat distribution and prevents product accumulation, significantly reducing the risk of fouling and maintaining consistent product quality. The system's vertical design optimizes floor space utilization while facilitating easy maintenance and cleaning procedures. Another significant advantage is the equipment's versatility in handling various product types, from solutions and suspensions to high-viscosity liquids and crystallizing materials. The precise control over processing parameters allows for exceptional product consistency and quality control. Energy efficiency is another key benefit, as the thin film design maximizes heat transfer efficiency, reducing operating costs and environmental impact. The ability to operate under vacuum conditions enables the processing of temperature-sensitive materials at lower temperatures, preserving product integrity and quality. The system's continuous operation capability increases productivity while reducing labor requirements and minimizing product loss. Additionally, the equipment's robust construction ensures long-term reliability and reduces maintenance requirements, contributing to lower operational costs and improved return on investment.

Practical Tips

Visit | Nanjing Ningkai presents at Pharmtech & Ingredients 2024 Russia

08

Feb

Visit | Nanjing Ningkai presents at Pharmtech & Ingredients 2024 Russia

View More
Heating and refrigeration circulator-I control the temperature

05

Feb

Heating and refrigeration circulator-I control the temperature

View More
Nanjing Ningkai Annual Meeting and thank you meeting came to a successful end!

05

Feb

Nanjing Ningkai Annual Meeting and thank you meeting came to a successful end!

View More

Get a Free Quote

Our representative will contact you soon.
Email
Name
Company Name
Message
0/1000

wiped thin film evaporator

Superior Heat Transfer Efficiency

Superior Heat Transfer Efficiency

The wiped thin film evaporator's exceptional heat transfer efficiency stems from its innovative design and operation principles. The system creates an ultra-thin product film, typically ranging from 0.5 to 2 millimeters, which is continuously renewed by rotating wiping elements. This thin film maximizes the surface area available for heat transfer while minimizing the distance heat must travel through the product. The continuous wiping action generates turbulent flow conditions, further enhancing heat transfer rates and ensuring uniform product treatment. This superior efficiency translates to shorter processing times, reduced energy consumption, and better product quality. The system's ability to maintain consistent film thickness across the entire heat transfer surface ensures uniform product treatment and prevents localized overheating, which is crucial for maintaining product integrity and quality.
Minimal Product Residence Time

Minimal Product Residence Time

One of the most critical advantages of wiped thin film evaporators is their ability to minimize product residence time while maintaining processing efficiency. The average residence time typically ranges from a few seconds to several minutes, depending on the application and operating conditions. This brief exposure to processing conditions is particularly crucial for heat-sensitive materials that could degrade under prolonged heating. The short residence time is achieved through the combination of thin film formation, efficient heat transfer, and continuous product movement through the system. The precise control over residence time allows for optimal processing conditions while preserving product quality and preventing unwanted chemical reactions or degradation. This feature is especially valuable in pharmaceutical and fine chemical applications where product stability is paramount.
Versatile Processing Capabilities

Versatile Processing Capabilities

The wiped thin film evaporator demonstrates remarkable versatility in handling a wide range of processing challenges. The system can effectively process materials with viscosities ranging from water-like fluids to highly viscous products exceeding 100,000 centipoise. This versatility extends to handling fouling materials, crystallizing products, and heat-sensitive substances that would be problematic in conventional evaporators. The equipment's ability to operate under vacuum conditions further expands its processing capabilities, allowing for the treatment of temperature-sensitive materials at reduced temperatures. The system can be easily adapted to different processing requirements through adjustments in operating parameters such as rotor speed, heating temperature, and vacuum level. This adaptability makes it suitable for various industries, including pharmaceuticals, chemicals, foods, and petrochemicals, where processing requirements can vary significantly.
